LIGHT TOWER FOR OUTDOOR WORK AND MOBILE LIGHTING

Introduction:

Light towers are designed to provide ample lighting in areas where traditional lighting sources may not be available or sufficient. They are often used in construction sites, outdoor events, emergency situations, and other locations that require temporary or portable lighting.

Characteristics:

Convenient movement
Easy operation
Flexible adjustment
Mobile lighting equipment
High stability

MOQ(Minimum order quantity): more than 10 sets

Product Detail

Product Tags

ADVANTAGE

Convenient movement

The lifting eye on the lifting beam facilitates easy movement of the lighting tower. The spring axle trailer and tow hitch meet the requirements .

Flexible adjustment

The lights can be adjusted manually at the non-lifting position; each light can be rotated 180°.The mast can be rotated 359°.

Multiple applications

Light towers can be used in a wide range of applications such as construction sites, outdoor events, emergency situations, and even in remote areas without access to electricity.

High stability

Emphasize quality, adopt advanced design, increase product stability, and extend service life.

Genset	Model	LGLP-9-6LED	LGLP-7.5-6LED	LGLPV-9-4LED
Trailer	Height	2550	2300	2360
	Length	3950	2700	2470
	Width	2170	1548	1450
	weight(Gross)	2250kg	1470kg	1340kg
	Tow hitch	50mm ball	50mm ball	50mm ball
	Axle	dual	single	single
	Tire and Rim size	LT235/85R16	175R13LT	175R13LT
	Tire quantity	4	2	2
	Brakes	hydraulic disc	drum brake	drum brake
Light	Type of lights	LED	LED	LED
	Number of lights	6	6	4
	Total light output (W)	2400	2400	1600
	Light tilt	hydraulic	hydraulic	Electric
Mast	Mast height(m)	9	7.5	9
	Mast rotation	hydraulic	Manual	Manual
	Mast raise	hydraulic	hydraulic	hydraulic
	Stabilizers support	hydraulic	mechanical	mechanical
	Tilt	hydraulic	hydraulic	hydraulic
GEN	Voltage(V)	48V DC	48V DC	48V DC
	Frequency(HZ)
	Output(KW)	4	4	4
Engine	Engine model	Z482D	Z482D	Z482D
	Brand	KUBOTA	KUBOTA	KUBOTA
	Engine power	4kw	4kw	4kw
	Engine speed(RPM)	1800	1800	1800
	Fuel consumption(g/kw.h)	240	240	240
	Emmission	TIER4	TIER4	TIER4
Alternator	Model	LGDC-4	LGDC-4	LGDC-4
	Brand	LONGEN	LONGEN	LONGEN
	Voltage(V)	48V DC	48V DC	48V DC
	Output(KW)	4	4	4
	Insulation grade
	Protection grade
Controller	Model
Controller	Brand
Load	40FT container load quantity(pcs)	3	8	8

Configuration

1. It is consist of generator, Pneumatic or Hydraulic Mast, lighting kits and trailer components.

2. The excellent-quality and multi-fault protection generator with the low-emission diesel engine and brushless alternator can power all lights stably and continuously.

3. Heavy-duty design for mining application.

4. Telescopic, 360 degree hydraulic mast rotation, mast up to 9 meters.

5. LED lights or Metal Halide lights with 120 degree hydraulic rotation.

6. Automatic start and stop plus Dawn and Dusk sensor.

7. 24 hours operation base fuel tank.

8. Residual current device(RCD) protection.

9. Hydraulic Disc brake, hand brake with ring or ball hitch for optional.

10. Equipped with forklift slots and crane lifting hook for easy lifting.

11. With Internal maintenance light and external maintenance night lights.

12. The outside emergency stop button can easily stop the gensets at any time.
